Silicon Steel
Oriented Electrical steel Silicon Steel Sheet Grain Oriented Silicon Steel Plate
Oriented silicon steel is a oriented silicon steel with grain, which has smaller iron loss and larger magnetic flux compared with the disorganized non-oriented non-oriented silicon steel. The silic...
DESCRIPTION
Oriented silicon steel is a oriented silicon steel with grain, which has smaller iron loss and larger magnetic flux compared with the disorganized non-oriented non-oriented silicon steel. The silicon steel sheet is divided into cold rolled and hot rolled. The most used is cold rolled silicon steel sheet. Cold rolled silicon steel sheet has excellent magnetic properties along the rolling direction, not only has high saturation flux density and low iron loss in the strong magnetic field, but also has good magnetic properties in the weak magnetic field (large initial permeability). This is because the cold rolling process reduces the content of impurities in the steel sheet, and causes coarse grains in the steel sheet, resulting in an increase in permeability and a decrease in hysteresis loss.
|
Non-Oriented Silicon Steel
|
||
|
Type
|
SPECIFICATIO
|
Thickness
|
|
Ordinary Type
|
B35A210 B35A230 B35A250 B35A270 B35A300 B35A360 B35A440 B35A550
|
0.35 mm
|
|
B50A230 B50A250 B50A270 B50A290 B50A310 B50A350 B50A400 B50A470
B50A540 B50A600 B50A700 B50A800 B50A1000 B50A1300
|
0.50 mm
|
|
|
B65A600 B65A700 B65A800 B65A1000 B65A1300 B65A1600
|
0.65 mm
|
|
|
Stress-relief annealing Type
|
B35AR300
|
0.35 mm
|
|
B50AR300 B50AR350 B50AR500 B50AR600
|
0.50 mm
|
|
|
High Magnetic Induction Type
|
B35AH230 B35AH250 B35AH300
|
0.35 mm
|
|
B50AH300 B50AH350 B50AH470 B50AH600 B50AH800 B50AH1000
|
0.50 mm
|
|
|
Oriented Silicon Steel
|
||
|
Ordinary Type
|
B23G110 B23G120
|
0.23 mm
|
|
B27G120 B27G130
|
0.27 mm
|
|
|
B30G120 B30G130 B30G140
|
0.30 mm
|
|
|
B35G135 B35G145 B35G155
|
0.35 mm
|
|
|
High Magnetic Induction Type
|
B23P075 B23P080 B23P090 B23P095 B23P100
|
0.23 mm
|
|
B27P095 B27P100 B27P110
|
0.27 mm
|
|
|
B30P100 B30P105 B30P110 B30P120
|
0.30 mm
|
|
|
B35P115 B35P125 B35P135
|
0.35 mm
|
|
