Silicon Steel
Grain Oriented Electrical Steel B35G135 for Electric Motor
Silicon steel is an iron-silicon alloy with a silicon content of 0.5%~4.8%. It is a soft magnetic material widely used in the field of electrical engineering. rand Name Nominal Thickness ...
DESCRIPTION
Silicon steel is an iron-silicon alloy with a silicon content of 0.5%~4.8%. It is a soft magnetic material widely used in the field of electrical engineering.
| rand Name | Nominal Thickness
(mm) |
Theoretical Density
kg/dm3 |
Max Iron Loss
W/kg P1.5/50 |
Min Magnetic InductionT B5000 | Min Number of Bends | Min Stacking Factor
% |
| 35WW230 | 0.35 | 7.60 | 2.30 | 1.62 | 2 | 95.0 |
| 35WW250 | 7.60 | 2.50 | 1.62 | 2 | ||
| 35WW270 | 7.65 | 2.70 | 1.62 | 2 | ||
| 35WW300 | 7.65 | 3.00 | 1.62 | 5 | ||
| 35WW360 | 7.65 | 3.60 | 1.63 | 5 | ||
| 35WW400 | 7.65 | 4.00 | 1.63 | 5 | ||
| 35WW440 | 7.70 | 4.40 | 1.65 | 5 |
FAQ
Q: what are your terms of payment?
A: 30% t / T advance deposit, 70% t / T balance within 5 days after the copy of bill of lading, 100% Irrevocable L / C at sight,100% irrevocable L / C 30-120 days after receipt of bill of lading, O / A.
Q: How can I get the price of needed product?
A: It’s the best way if you can send us the material, size and surface, so we can produce for u to check the quality.If you still have any confusion, just contact us, we would like to be helpful.
Q:What about your price?
A:Our price is very competitive because we are a factory. Pls feel free to contact us if you are interested in our products.
