Silicon Steel

Cold Rolled Grain Oriented Silicon Electrical Steel With Certificate

Cold Rolled Grain Oriented Silicon Electrical Steel With Certificate

Oriented silicon steel: It has strong directionality, the lowest iron loss value in the rolling direction, the highest magnetic permeability, and a higher magnetic induction value under a certain m...

Whatsapp Send Email
DESCRIPTION

Oriented silicon steel: It has strong directionality, the lowest iron loss value in the rolling direction, the highest magnetic permeability, and a higher magnetic induction value under a certain magnetization field.

Standard Magnetic and Technical Properties
Product Name
CRGO Silicon Steel Sheet
Product model(Grade)
C27QH100
Type
Domain refined high induction type
Thickness
0.27
Density
7.65
Core loss(w/kg)
0.96-1.0(P17/50)
Induction(T)
1.92
Min. induction(T)
1.86

Cold Rolled Grain Oriented Silicon Electrical Steel With Certificate

Our advantage

1.Excellent Electromahnetic Property

The GO electrical steel has the characteristics of low iron loss, high magnetic induction and stable performance. To ensure lower cost of downstream products, energy-saving effect better.

2.Outstanding Processability
Excellent mechanical properties are convenient for the users to slit, cut and laminate.
3.Excellent Dimensional Accuracy
The products has smooth surface, uniform thickness, small intra-plate deviation and high lamination factor.
4.Excellent Performance of Insulating Coating
The product has the advantages of surface insulation, uniform coating, good adhesion, good heat resistance and good corrosion resistance, and good insulation between layers.
