Silicon Steel
B35P115 orientated silicon steel
Lower core losses result in improved energy efficiency in electrical devices. Product Name oriented silicon steel Grade B35P115 Thickness 0.35mm Nominal thickness tolerance...
DESCRIPTION
Lower core losses result in improved energy efficiency in electrical devices.
| Product Name | oriented silicon steel |
| Grade | B35P115 |
| Thickness | 0.35mm |
| Nominal thickness tolerance(mm) | +0.010-0.025 |
| Longitudinal thickness deviation(mm) | +0.0150 |
| Assumed density | 7.65kg/dm3 |
| Length | Coil Or As Required |
| Tensile strength (L) | 369mpa |
| Yield strength (L) | 347mpa |
| Elongation (L) | 13% |
| Surface Treatment | Coated |
| Application | Widely used in Transformer, reactor, mutual inductor, motor. |
Magnetic domain-refined B35P115 orientated silicon steel are typically designed with anisotropic magnetic properties, meaning their magnetic characteristics are different along specific crystallographic directions. This anisotropy is achieved by carefully aligning the crystal grains during the manufacturing process. In the presence of a magnetic field, the material exhibits superior magnetic properties along the rolling direction compared to other directions, enhancing its efficiency in transformer cores.
FAQ
1. Q: Are you a manufacturer?
A: Yes, we are manufacturer. We have our own factory and our own company, I believe we will be your most suitable supplier.We have our own factory and our own company, I believe we will be your most suitable supplier.
2.Q.Can your products be customized?
A.Yes, we can produce and process according to your requirements.
3.Q: How do you guarantee the quality of your products?
A: Each product is produced by certified workshops and inspected piece by piece according to national QA/QC standards. We can also issue a warranty to our customers to guarantee the quality.
