Silicon Steel
B30P095 orientated silicon steel
Oriented silicon steel is used in the cores of electric motors and generators to optimise energy conversion efficiency. Product Name oriented silicon steel Grade B30P095 Thicknes...
DESCRIPTION
Oriented silicon steel is used in the cores of electric motors and generators to optimise energy conversion efficiency.
| Product Name | oriented silicon steel |
| Grade | B30P095 |
| Thickness | 0.30mm |
| Nominal thickness tolerance(mm) | +0.010-0.025 |
| Longitudinal thickness deviation(mm) | +0.0150 |
| Assumed density | 7.65kg/dm3 |
| Length | Coil Or As Required |
| Tensile strength (L) | 372mpa |
| Yield strength (L) | 346mpa |
| Elongation (L) | 14% |
| Surface Treatment | Coated |
| Application | Widely used in Transformer, reactor, mutual inductor, motor. |
he grain orientation process in oriented silicon steel aligns the crystal structure, leading to improved magnetic anisotropy. This alignment allows the material to exhibit better magnetic properties in a specific direction, further reducing energy losses and improving performance.
FAQ
1.Q.Are you a manufacturer?
A.Yes, we are a manufacturer and a well-known company with an early start in China’s steel industry.
2.Q: What product information do I need to provide?
A: You need to provide the grade, width, thickness, coating and tonnage you need to buy.
3.Q.Do the products have quality inspection before loading?
A.Of course, all our products are strictly quality inspected before packing, unqualified products will be destroyed, we absolutely accept third party inspection, you are welcome to visit us by all means.
