Silicon Steel
B20R070 orientated silicon steel
Magnetic domain refinement silicon steel is a special silicon steel material with excellent magnetic properties Product Name oriented silicon steel Grade B20R070 Thickness 0.20m...
DESCRIPTION
Magnetic domain refinement silicon steel is a special silicon steel material with excellent magnetic properties
| Product Name | oriented silicon steel |
| Grade | B20R070 |
| Thickness | 0.20mm |
| Nominal thickness tolerance(mm) | +0.010-0.015 |
| Longitudinal thickness deviation(mm) | +0.0120 |
| Assumed density | 7.65kg/dm3 |
| Length | Coil Or As Required |
| Tensile strength (L) | 371mpa |
| Yield strength (L) | 354mpa |
| Elongation (L) | 9% |
| Surface Treatment | Coated |
| Application | Widely used in Transformer, reactor, mutual inductor, motor. |
Magnetic induction intensity: the magnetic induction intensity generated by B20R070 orientated silicon steel under the action of a magnetic field.
Coercivity: the strength of the reverse magnetic field that needs to be applied to B20R070 orientated silicon steel when it is demagnetised.
FAQ
1.Q.What can you do for us?
A.We always shorten delivery time for our buyer.We always package steel products well.We always fix steel product in container well to make it safe arrive at destination portWe always provide best and professional forward service and after sales service.
2. Q: What services do you provide?
A: Customized service for each customer, please feel free to contact us!
3. Q. How can I learn about your quality assurance?
A. Visiting our factory is the best way to understand each other.
4.Q.Can you send samples?
A.Sure, we can send samples to all over the world. But customers need to pay the courier fee.
