Silicon Steel
B18R060 orientated silicon steel
Magnetic domain refinement orientated silicon steel is a special electrical steel material with excellent magnetic domain refinement and high orientation. Product Name oriented silicon stee...
DESCRIPTION
Magnetic domain refinement orientated silicon steel is a special electrical steel material with excellent magnetic domain refinement and high orientation.
| Product Name | oriented silicon steel |
| Grade | B18R060 |
| Thickness | 0.18mm |
| Nominal thickness tolerance(mm) | +0.010-0.015 |
| Longitudinal thickness deviation(mm) | +0.0120 |
| Assumed density | 7.65kg/dm3 |
| Length | Coil Or As Required |
| Tensile strength (L) | 369mpa |
| Yield strength (L) | 350mpa |
| Elongation (L) | 13% |
| Surface Treatment | Coated |
| Application | Widely used in Transformer, reactor, mutual inductor, motor. |
High saturation induction: Domain RefinedB18R060 orientated silicon steel are able to achieve high saturation induction at lower magnetic field strengths, allowing them to accommodate higher magnetic flux in a small volume.
Low iron loss: Due to their optimised domain structure, domain-refined Si-steels have low iron loss and are highly efficient in converting magnetic energy in alternating magnetic fields.
