Silicon Steel
0.2mm Thick Oriented Silicon Steel Sheet
Cold-rolled oriented silicon steel, also known as cold-rolled transformer steel, is an important ferrosilicon alloy used in transformer (iron core) manufacturing industry. Its production process is...
DESCRIPTION
Cold-rolled oriented silicon steel, also known as cold-rolled transformer steel, is an important ferrosilicon alloy used in transformer (iron core) manufacturing industry. Its production process is complex, manufacturing technology is strict.
Product Description
| Product Name | Oriented silicon steel sheet |
| Material | Oriented electrical steel |
| Grade | C11023/27JG120/27PG120/27Z120/30Z120/23JGH090/M19/20SQG080/ 20SQG085/20SQGD070/20SQGD075/23SQG85/23SQG95/27SQG90/27 SQG95/30SQG100 Etc. |
| Nominal Thickness | 0.20mm,0.23mm,0.27mm,0.30mm |
| Nominal Width | 800~1200mm,can be divided into various widths |
| Thickness Tolerance | ±0.020mm |
| Transverse Thickness Tolerance | ≤0.015mm |
| Longitudinal Thickness Tolerance | ≤0.020mm |
| Width Tolerance | 0~+1.0mm |
| Standard Electromagnetic Properties | High Magnetic Induction Type/Domain Refined High Magnetic Induction Type |
| Standard | ASTM,GB,JS,DIN,AISI |
| Surface Treatment | Cold Rolled |
| Certificate | CE SGS BV |
| Processing Service | Welding, Punching, Cutting, Bending, Sand Blasting, Spray paint |
| Application | High frequency working motor Miniature power supply transformer Instrument use transformer Reactor Welding machine use transformer Power switch Manostat/Magnetic sealing unit Electromagnet for accelerator |
| MOQ | 2Ton |
| Delivery time | 30 workdays after receiving deposit |
FAQ
Q: Can you send samples?
A: Of course, we can send the samples to all parts of the world. Our samples are free of charge, but the customer
needs to bear the express fee.
Q: What product information do I need to provide?
A: You need to provide the grade, width, thickness, coating and tonnage you need to buy.
Q: About product price?
A: Due to the cyclical change of raw material prices, the prices are different in different periods.
