Silicon Steel
Grain Oriented Electrical Steel Coil sheet CRGO Silicon Steel Coil
CRGO is the abbreviation for Cold Rolled Grain Oriented silicon Steel, which is used in particular to laminate any heavy transformer as a core. Type Grade Thickness (mm) Available width r...
DESCRIPTION
CRGO is the abbreviation for Cold Rolled Grain Oriented silicon Steel, which is used in particular to laminate any heavy transformer as a core.
| Type | Grade | Thickness (mm) | Available width range(mm) | ID | Density (kg/dm³) | P17/50Max. Core Loss(W/kg) | B8Min. Induction(T) |
| Common Type | B23G110 | 0.23 | 700-1200 | 508 | 7.65 | 1.10 | 1.80 |
| B27G120 | 0.27 | 1.20 | 1.80 | ||||
| B30G120 | 0.30 | 1.20 | 1.80 | ||||
| B30G130 | 1.30 | 1.80 | |||||
| B30G140 | 1.40 | 1.80 | |||||
| B35G135 | 0.35 | 1.35 | 1.80 | ||||
| B35G145 | 1.45 | 1.80 | |||||
| B35G155 | 1.55 | 1.80 | |||||
| High Induction Type | B23P090 | 0.23 | 0.90 | 1.87 | |||
| B23P095 | 0.95 | 1.87 | |||||
| B23P100 | 1.00 | 1.87 | |||||
| B27P095 | 0.27 | 0.95 | 1.88 | ||||
| B27P100 | 1.00 | 1.88 | |||||
| B27P110 | 1.10 | 1.88 | |||||
| B30P100 | 0.30 | 1.00 | 1.88 | ||||
| B30P105 | 1.05 | 1.88 | |||||
| B30P110 | 1.10 | 1.88 | |||||
| B30P120 | 1.20 | 1.88 | |||||
| B35P135 | 0.35 | 1.35 | 1.88 | ||||
| B35P155 | 1.55 | 1.88 | |||||
| Domain Refined High Induction Type | B23R080 | 0.23 | 0.80 | 1.87 | |||
| B23R085 | 0.85 | 1.87 | |||||
| B23R090 | 0.90 | 1.87 | |||||
| B27R090 | 0.27 | 0.90 | 1.87 | ||||
| B27R095 | 0.95 | 1.87 |
Our Advantages：
1) All standard steel products are stocked, timely shipping as per clients request.
2) Lead time generally about 15-30 working days after receiving the deposit.
3) Standard export package,suit for all kinds of transport,or as required.
