Silicon Steel
GNEE M19 Prime Quality Cold Rolled CRGO Grain Oriented Lamination Silicon Steel Plate Sheet Strip Coil
M19 oriented silicon steel is a high-performance material that is widely used in the construction of electrical power equipment. Its unique grain orientation and excellent magnetic properties make ...
DESCRIPTION
M19 oriented silicon steel is a high-performance material that is widely used in the construction of electrical power equipment. Its unique grain orientation and excellent magnetic properties make it an ideal choice for demanding applications where efficiency and reliability are essential.
Products Description:
|
Product Name
|
GNEE M19 Prime Quality Cold Rolled CRGO Grain Oriented Lamination Silicon Steel Plate Sheet Strip Coil |
|
Brand
|
AiSi, ASTM, BS, DIN, GB, JIS
|
|
Material
|
silicon steel / Size: can be customized
|
|
Grade
|
M19
|
|
Capacity
|
about 2000 tons per month for the coil product
|
|
Width
|
40mm-1200mm 1000/1100/1200(mm) or per customer’s request
|
|
Nominal Thickness
|
0.1mm
|
|
Max.Core Loss
|
50w1300 7.5W/kg,50W800 5.8W/kg,50W600 4.2W/kg.
|
|
Min.Induction
|
50w1300 1.74T,50W800 1.70T,50W600 1.67T.
|
|
Min.Lamination Factor
|
97%
|
|
Application
|
compressor motor,electric machinery,rectifier,transformer,etc.
|
FAQ:
Q:It’s my first time to import steel products, can you help me with it?
A:Sure,we have agent to arrange the shipment, we will do it together with you.
