Silicon Steel
China Electrical Core Silicon Lamination Steel Coil/SheetC27QH120, Relay Steel and Transformer Steel
Cold rolled silicon steel have good processability, with good flatness and excellent surface, are available with different thickness and width combinations. Product Name CRGO Silicon St...
DESCRIPTION
Cold rolled silicon steel have good processability, with good flatness and excellent surface, are available with different thickness and width combinations.
|
Product Name
|
CRGO Silicon Steel Sheet
|
|
Product model(Grade)
|
C27QH120
|
|
Type
|
Domain refined high induction type
|
|
Thickness
|
0.27
|
|
Density
|
7.65
|
|
core loss(w/kg)
|
1.06-1.16(P17/50）
|
|
induction(T）
|
1.92
|
|
Min. induction(T）
|
1.86
|
Our advantage
1.Excellent Electromahnetic Property
The GO electrical steel has the characteristics of low iron loss, high magnetic induction and stable performance. To ensure lower cost of downstream products, energy-saving effect better.
2.Outstanding Processability
Excellent mechanical properties are convenient for the users to slit, cut and laminate.
3.Excellent Dimensional Accuracy
The products has smooth surface, uniform thickness, small intra-plate deviation and high lamination factor.
4.Excellent Performance of Insulating Coating
The product has the advantages of surface insulation, uniform coating, good adhesion, good heat resistance and good corrosion resistance, and good insulation between layers.
