Silicon Steel
B50A700 Cold Rolled Electrical Steel Silicon Steel Coil
B50A700 is up to 0.8% -4.8% silicon electrical steel, after hot and cold rolled steel. Usually the thickness of 1mm or less. B50A700 steel Mechanical Properties Grade Nominal thick...
DESCRIPTION
B50A700 is up to 0.8% -4.8% silicon electrical steel, after hot and cold rolled steel. Usually the thickness of 1mm or less.
B50A700 steel Mechanical Properties
|
Grade |
Nominal thickness（mm） |
tensile strength L（N/mm2） |
Yield Strength L（N/mm2） |
Elongation L（%） |
Hardness HV1 |
Bending frequency (times) |
Stacking factor（%） |
|
B50A700 |
0.50 |
7.80 |
382 |
247 |
38 |
120 |
≥15 |
B50A700 steel sheet/plate Electromagnetic induction standard
|
Grade |
Nominal thickness（mm） |
Theoretical density（kg/dm3） |
Maximum core loss P17/50 |
minimum magnetic induction（T） |
|
B50A700 |
0.50 |
7.80 |
7.00 |
1.70 |
